ELECTRONIC SPEED GOVERNOR
Assembly ID: 1460.046-01
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 8007450 | TIMINGGEAR HOUSIN | 1 | ||
| 2 | 4858609 | WASHER | 1 | ||
| 3 | 16992411 | THREADED PLUG | 1 | ||
| 4 | 17088974 | SPRING WASHER | 4 | ||
| 5 | 4934404 | SCREW | 4 | ||
| 6 | 14309221 | SCREW | 4 | ||
| 7 | 16689134 | SOCKET-HEAD SCREW | 4 | ||
| 8 | 8108716 | NUT | 1 | ||
| 9 | 8015485 | GASKET | 1 | ||
| 10 | 10717311 | NUT | 1 |
Applies to engines
| Engine | Family | |
|---|---|---|
| GE8210SRi26.02A955 | GE8210SRi26 | view |
| GE8210SRi27.00A955 | GE8210SRi27 | view |
| GS8210SRi26.02 | GS8210SRi26 | view |
| GS8210SRi27.00 | GS8210SRi27 | view |
| GS8210SRi26.02A601 | GS8210SRi26 | view |
| GS8210SRi26.02A602 | GS8210SRi26 | view |
| GS8210SRi26.02A651 | GS8210SRi26 | view |
| GS8210SRi27.00A601 | GS8210SRi27 | view |
| 8210SRi26.02 | 8210SRi26 | view |
| 8210SRi27.00 | 8210SRi27 | view |
| 8210SRi26.02A550 | 8210SRi26 | view |
| 8210SRi26.02A580 | 8210SRi26 | view |
| 8210SRi27.00A550 | 8210SRi27 | view |
| 8210SRi27.00A580 | 8210SRi27 | view |
| 8210SRi26.03A602 | 8210SRi26 | view |
| 8210SRi27.01A603 | 8210SRi27 | view |
