ENGINE BREATHERS
Assembly ID: 0450.228
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 504089127 | BREATHER | 1 | ||
| 2 | 504050244 | SHAFT SEAL | 1 | ||
| 3 | 17291281 | O-RING | 1 | ||
| 4 | 16585825 | HEXAGON BOLT | 3 | ||
| 5 | 16867073 | SPRING LOCKWASHER | 1 | ||
| 6 | 504075145 | AIR CLEANER | 1 | ||
| 7 | 11500324 | STUD | 3 | ||
| 8 | 17044721 | HEXAGON NUT | 3 |
Applies to engines
| Engine | Family | |
|---|---|---|
| F1CE0481F*A001 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.10P002 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0481F*C501 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.40A001 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.40A002 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0487K*C502 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.80A001 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.80A002 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.80A003 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0441A*A003 | SOFIM HPI 3.0L CNG | view |
| F1CE0481F*C503 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENTG20.00A002 | SOFIM HPI 3.0L CNG | view |
| F1CE0481F*C001 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.30A001 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0481H*C003 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT425.10A001 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.91L003 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0481F*C504 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.70A002 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0481F*A002 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENT422.11A001 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0481L*A003 | SOFIM HPI 3.0L - EURO 4 | view |
| S30ENTC24.00L008 | SOFIM HPI 3.0L - EURO 4 | view |
| F1CE0481F*A003 | SOFIM HPI 3.0L - EURO 4 | view |
