INTAKE MANIFOLD
Assembly ID: 0710.001
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 4785055 | INTAKE ELBOW | 1 | ||
| 2 | 98400791 | INTAKE ELBOW GASK. | 1 | ||
| 3 | 4851921 | INTAKE ELBOW GASK. | 1 | ||
| 4 | 4577310 | THREADED PLUG | 1 | ||
| 5 | 17089574 | WASHER | 5 | ||
| 6 | 16605524 | HEXAGON BOLT | 5 | ||
| 7 | 10279560 | SEAL GASKET | 1 |
