| 1 |
98428304
|
INTAKE ELBOW
|
|
1
|
|
| 2 |
4807812
|
INTAKE ELBOW
|
|
1
|
|
| 3 |
4789747
|
INTAKE ELBOW GASK.
|
|
4
|
|
| 4 |
13516811
|
STUD
|
|
2
|
|
| 5 |
15971821
|
SCREW
|
|
8
|
|
| 6 |
16729324
|
STUD
|
|
2
|
|
| 7 |
4789748
|
WASHER
|
|
8
|
|
| 8 |
17290681
|
O-RING
|
|
2
|
|
|
14465281 |
O-RING |
|
2 |
|
| 9 |
4807816
|
INTAKE ELBOW
|
|
1
|
|
| 10 |
17089474
|
SPRING WASHER
|
|
2
|
|
| 11 |
16606124
|
HEXAGON BOLT
|
|
1
|
|
| 12 |
17037931
|
HEXAGON NUT
|
|
2
|
|
| 13 |
17793804
|
WASHER
|
|
4
|
|
| 14 |
16043721
|
HEXAGON BOLT
|
|
3
|
|
|
16043724 |
HEXAGON BOLT |
|
3 |
|
| 15 |
17751985
|
WASHER
|
|
2
|
|
| 16 |
16993711
|
THREADED PLUG
|
|
2
|
|
| 17 |
16992240
|
THREADED PLUG
|
|
1
|
|
| 18 |
4858607
|
WASHER
|
|
1
|
|
| 19 |
8018124
|
AIR PIPE/DUCT
|
|
1
|
|
| 20 |
17291181
|
O-RING
|
|
1
|
|
| 21 |
8108560
|
RETAINER
|
|
1
|
|
| 22 |
16605524
|
HEXAGON BOLT
|
|
1
|
|
| 23 |
16607624
|
SCREW
|
|
1
|
|
| 24 |
17090174
|
SPRING WASHER
|
|
1
|
|
| 25 |
17038121
|
HEXAGON NUT
|
|
1
|
|
|
17038131 |
HEXAGON NUT |
|
1 |
|
