INTAKE MANIFOLD
Assembly ID: 0710.131
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 500332035 | INTAKE ELBOW | 1 | ||
| 2 | 98425767 | INTAKE ELBOW GASK. | 4 | ||
| 3 | 99486343 | HEXAGON NUT | 8 | ||
| 4 | 500330556 | INTAKE ELBOW | 1 | ||
| 5 | 16729424 | STUD | 4 | ||
| 6 | 99473619 | INTAKE ELBOW GASK. | 1 | ||
| 7 | 17044731 | HEXAGON NUT | 4 |
Applies to engines
| Engine | Family | |
|---|---|---|
| 8140SRC21.00 | 8140SRC21 | view |
