| 1 |
1907550
|
CRANK SHAFT
|
|
1
|
|
|
98415921 |
CRANK SHAFT |
|
1 |
|
| 2 |
1907556
|
CRANK SHAFT
|
|
1
|
|
| 3 |
98419205
|
CRANK SHAFT
|
|
1
|
|
| 4 |
7475037
|
CONN.ROD ASSY.
|
|
4
|
|
|
7473171 |
CONN.ROD ASSY. |
|
4 |
|
| 5 |
7302028
|
BIG-END BUSH
|
|
4
|
|
| 6 |
4722004
|
BIG-END BOLT
|
|
8
|
|
| 7 |
98419244
|
CAMSHAFT PINION
|
|
1
|
|
|
10332010 |
CAMSHAFT PINION |
|
1 |
|
|
98419310 |
CAMSHAFT PINION |
|
1 |
|
| 8 |
10332010
|
PARALLEL PIN
|
|
1
|
|
| 9 |
4655844
|
KEY
|
|
1
|
|
| 10 |
14328101
|
LOCK PLUG
|
|
4
|
|
| 11 |
98426373
|
CENTERING RING
|
|
1
|
|
| 12 |
24941350
|
ENGINE BEARINGS
|
|
1
|
|
| 13 |
4707366
|
CAMSHAFT PINION
|
|
1
|
|
| 14 |
98415920
|
CAMSHAFT PINION
|
|
1
|
|
| 15 |
98449079
|
CONN.ROD ASSY.
|
|
4
|
|
|
7473171 |
CONN.ROD ASSY. |
|
4 |
|
| 16 |
98425915
|
BIG-END BOLT
|
|
4
|
|
|
98460577 |
BIG-END BOLT |
|
4 |
|
