| 1 |
500305398
|
PROTECTION
|
|
1
|
|
|
504020090 |
PROTECTION |
|
1 |
|
| 2 |
98419390
|
TIMING BELT
|
|
1
|
|
|
500055907 |
TIMING BELT |
|
1 |
|
| 3 |
99455320
|
COVER
|
|
1
|
|
|
504010962 |
COVER |
|
1 |
|
| 4 |
4740847
|
ENGINE BEARINGS
|
|
1
|
|
| 6 |
17095104
|
WASHER
|
|
1
|
|
|
17095125 |
WASHER |
|
1 |
|
| 7 |
16605524
|
HEXAGON BOLT
|
|
3
|
|
| 8 |
99454876
|
CAMSHAFT PINION
|
|
1
|
|
|
504090595 |
CAMSHAFT PINION |
|
1 |
|
| 9 |
99469896
|
SUPPORT
|
|
1
|
|
| 10 |
500342834
|
HEXAGON BOLT
|
|
3
|
|
| 12 |
4719078
|
SPACER
|
|
1
|
|
| 13 |
12646721
|
WASHER
|
|
1
|
|
| 15 |
4740846
|
ENGINE BEARINGS
|
|
1
|
|
| 17 |
4279745
|
BELT TENSIONER
|
|
1
|
|
| 18 |
17037931
|
HEXAGON NUT
|
|
1
|
|
| 21 |
4849127
|
SUPPORT
|
|
1
|
|
| 22 |
17089474
|
SPRING WASHER
|
|
3
|
|
| 23 |
7300035
|
SPACER
|
|
1
|
|
| 24 |
98415210
|
INJ.PUMP DRIV.GEA
|
|
1
|
|
| 25 |
14337521
|
LOCKING SCREW
|
|
3
|
|
|
500372179 |
LOCKING SCREW |
|
3 |
|
| 26 |
17798374
|
SPRING WASHER
|
|
1
|
|
| 27 |
17038221
|
HEXAGON NUT
|
|
1
|
|
|
17038225 |
HEXAGON NUT |
|
1 |
|
| 32 |
98479895
|
SPACING BAR
|
|
1
|
|
| 34 |
16288424
|
HEXAGON BOLT
|
|
1
|
|
| 35 |
99447327
|
SPACER
|
|
1
|
|
| 36 |
500341406
|
COVER
|
|
1
|
|
|
504022580 |
COVER |
|
1 |
|
| 37 |
99485223
|
HEXAGON BOLT
|
|
1
|
|
| 38 |
16585924
|
HEXAGON BOLT
|
|
1
|
|
| 39 |
16597224
|
HEXAGON BOLT
|
|
1
|
|
| 40 |
12647724
|
WASHER
|
|
1
|
|
