| 1 |
4736331
|
WASHER
|
|
2
|
|
| 2 |
4836627
|
TIMING CHAIN
|
|
1
|
|
| 3 |
500358679
|
INJ.PUMP DRIV.GEA
|
|
1
|
|
| 4 |
99457143
|
SLIDING SHOE
|
|
1
|
|
| 5 |
7301034
|
PIN
|
|
1
|
|
| 6 |
7301039
|
SLIDING SHOE
|
|
1
|
|
| 7 |
4859435
|
BELT TENSIONER
|
|
1
|
|
| 8 |
98421301
|
FLAT ENGINE GASKET
|
|
1
|
|
| 9 |
500359647
|
TIMING INTERM.GEA
|
|
1
|
|
| 10 |
16605624
|
HEXAGON BOLT
|
|
3
|
|
|
16605635 |
HEXAGON BOLT |
|
3 |
|
| 11 |
7302381
|
SLIDING SHOE
|
|
1
|
|
|
504132333 |
SLIDING SHOE |
|
1 |
|
| 12 |
7302382
|
SLIDING SHOE
|
|
1
|
|
| 13 |
17037821
|
HEXAGON NUT
|
|
4
|
|
| 14 |
14453281
|
O-RING
|
|
1
|
|
| 15 |
16603734
|
HEXAGON BOLT
|
|
2
|
|
| 16 |
16597224
|
HEXAGON BOLT
|
|
3
|
|
| 17 |
17089474
|
SPRING WASHER
|
|
3
|
|
| 18 |
17088474
|
WASHER
|
|
7
|
|
| 19 |
500372179
|
LOCKING SCREW
|
|
3
|
|
| 20 |
12646721
|
WASHER
|
|
1
|
|
