| 1 |
8011420
|
WIRE/CABLE
|
|
1
|
|
| 2 |
8111233
|
GASKET
|
|
1
|
|
| 3 |
8010375
|
FUEL LINE
|
|
1
|
|
| 4 |
8112247
|
PIPE SOCKET
|
|
1
|
|
|
FPT8112247 |
PIPE SOCKET |
|
1 |
|
| 5 |
4858607
|
WASHER
|
|
2
|
|
| 6 |
4864082
|
BANJO BOLT
|
|
1
|
|
| 7 |
8011707
|
FUEL LINE
|
|
1
|
|
| 8 |
4858608
|
SEAL GASKET
|
|
4
|
|
| 9 |
4864083
|
SCREW CONNECTOR
|
|
2
|
|
| 10 |
8013905
|
FUEL LINE
|
|
1
|
|
| 11 |
16504011
|
PIPE SOCKET
|
|
2
|
|
|
16504015 |
PIPE SOCKET |
|
2 |
|
| 12 |
8013906
|
FUEL LINE
|
|
1
|
|
| 13 |
4858606
|
GASKET
|
|
4
|
|
| 14 |
4864079
|
SCREW CONNECTOR
|
|
2
|
|
| 15 |
16689124
|
CYLIND-HEAD SCREW
|
|
2
|
|
| 16 |
8011590
|
FUEL LINE
|
|
1
|
|
| 17 |
8011711
|
COVER
|
|
1
|
|
| 18 |
16504714
|
T-COUPLING
|
|
1
|
|
| 19 |
16500214
|
THREADED UNION
|
|
3
|
|
|
16500215 |
THREADED UNION |
|
3 |
|
| 20 |
98474308
|
SEAL GASKET
|
|
3
|
|
|
5801696011 |
SEAL GASKET |
|
3 |
|
