| 1 |
500349325
|
FASTENING BRACKET
|
|
1
|
|
| 7 |
4851923
|
FLAT ENGINE GASKET
|
|
1
|
|
| 8 |
17089474
|
SPRING WASHER
|
|
6
|
|
| 9 |
17094914
|
WASHER
|
|
6
|
|
| 10 |
17037931
|
HEXAGON NUT
|
|
6
|
|
| 11 |
99483335
|
INJECT.PUMP SPIND
|
|
1
|
|
| 12 |
10335910
|
PARALLEL PIN
|
|
1
|
|
| 15 |
16596924
|
HEXAGON BOLT
|
|
1
|
|
| 21 |
500388113
|
RETAINER
|
|
4
|
|
| 21 |
99453918
|
RETAINER
|
|
4
|
|
| 24 |
17090274
|
WASHER
|
|
4
|
|
| 32 |
768389
|
CIRCLIP
|
|
1
|
|
| 35 |
756671
|
WASHER
|
|
4
|
|
| 36 |
500366314
|
HIGH PRESSURE PUMP
|
|
1
|
|
| 37 |
500319674
|
O-RING
|
|
1
|
|
| 38 |
99487290
|
INJECT.PUMP BUSH
|
|
1
|
|
| 39 |
7303345
|
NUT
|
|
1
|
|
| 40 |
500354490
|
SUPPORT
|
|
1
|
|
| 41 |
16746824
|
STUD
|
|
3
|
|
| 42 |
500313105
|
ELECTRO INJECTOR
|
|
4
|
|
|
500384284 |
ELECTRO INJECTOR |
|
4 |
|
| 43 |
14307924
|
CYLIND-HEAD SCREW
|
|
4
|
|
| 44 |
500398225
|
HYDRAULIC CYLINDER
|
|
1
|
|
| 45 |
17044735
|
NUT
|
|
3
|
|
| 46 |
500340681
|
INJECTION LINE SET
|
|
1
|
|
| 47 |
500354019
|
SET OF WIRING
|
|
1
|
|
| 48 |
500315270
|
CHOCK
|
|
1
|
|
| 49 |
500332712
|
RUBBER SLEEVE
|
|
1
|
|
| 50 |
500399013
|
THREADED UNION
|
|
1
|
|
| 51 |
500372234
|
SENSOR
|
|
1
|
|
|
42569152 |
SENSOR |
|
1 |
|
| 52 |
500399014
|
THREADED UNION
|
|
4
|
|
| 53 |
500372236
|
WASHER
|
|
1
|
|
| 54 |
500378001
|
SPRING CLAMP
|
|
4
|
|
| 55 |
500394220
|
HYDRAULIC CYLINDER
|
|
1
|
|
|
504088076 |
HYDRAULIC CYLINDER |
|
1 |
|
| 56 |
504032951
|
SET OF WIRING
|
|
1
|
|
| 57 |
504070031
|
INJECTION LINE SET
|
|
1
|
|
| 59 |
504112900
|
SET OF WIRING
|
|
1
|
|
| 60 |
42538467
|
FLAT ENGINE GASKET
|
|
1
|
|
| 61 |
42538165
|
GOVERNOR/REGULATOR
|
|
1
|
|
| 62 |
42541074
|
GASKET
|
|
1
|
|
|
42561271 |
GASKET |
|
1 |
|
| 63 |
42541075
|
O-RING
|
|
1
|
|
| 64 |
42533116
|
CYLIND-HEAD SCREW
|
|
2
|
|
| 65 |
504088073
|
HYDRAULIC CYLINDER
|
|
1
|
|
| 66 |
504088076
|
INJECTION LINE SET
|
|
1
|
|
