| 1 |
17292481
|
O-RING
|
|
1
|
|
| 2 |
4882440
|
RING
|
|
12
|
|
| 3 |
99462519
|
HEXAGON BOLT
|
|
8
|
|
| 4 |
98469608
|
RUBBER PAD
|
|
2
|
|
| 5 |
98469609
|
INJECT.PUMP SPIND
|
|
1
|
|
| 6 |
99446392
|
SUPPORT
|
|
1
|
|
| 7 |
500300622
|
INJECT.PUMP SPIND
|
|
1
|
|
| 8 |
4529701
|
BEARING BUSH
|
|
2
|
|
| 9 |
99448170
|
INJECT.PUMP SLEEVE
|
|
1
|
|
| 10 |
98418371
|
INJ.PUMP DRIV.GEA
|
|
1
|
|
| 11 |
99439042
|
INJECT.PUMP DAMPE
|
|
1
|
|
| 12 |
500304324
|
INJECT.PUMP SLEEVE
|
|
1
|
|
| 13 |
10206320
|
KEY
|
|
1
|
|
| 14 |
10731121
|
WASHER
|
|
1
|
|
| 15 |
12626024
|
SPRING WASHER
|
|
4
|
|
| 16 |
17090274
|
WASHER
|
|
6
|
|
| 17 |
99450170
|
HEXAGON BOLT
|
|
1
|
|
| 18 |
16980931
|
HEXAGON NUT
|
|
1
|
|
| 19 |
17038221
|
HEXAGON NUT
|
|
6
|
|
|
17038225 |
HEXAGON NUT |
|
6 |
|
| 20 |
17042931
|
NUT
|
|
1
|
|
| 21 |
98462135
|
WASHER
|
|
2
|
|
| 23 |
13449424
|
STUD
|
|
6
|
|
| 24 |
11306924
|
HEXAGON BOLT
|
|
3
|
|
| 25 |
98494989
|
SHAFT SEAL
|
|
1
|
|
| 26 |
500300648
|
HEXAGON NUT
|
|
1
|
|
| 27 |
17090174
|
SPRING WASHER
|
|
4
|
|
| 28 |
4882441
|
WASHER
|
|
8
|
|
| 29 |
99447927
|
BUSH
|
|
8
|
|
| 30 |
99478033
|
DOWEL PIN
|
|
1
|
|
| 31 |
500330982
|
HEXAGON BOLT
|
|
1
|
|
