| 1 |
12647124
|
WASHER
|
|
5
|
|
| 2 |
4851923
|
FLAT ENGINE GASKET
|
|
1
|
|
| 3 |
4799342
|
INJECT.PUMP BUSH
|
|
1
|
|
| 4 |
4799086
|
SPRING WASHER
|
|
1
|
|
| 5 |
4791132
|
SPACING BAR
|
|
1
|
|
| 6 |
98401723
|
HEXAGON BOLT
|
|
8
|
|
| 7 |
4851922
|
FLAT ENGINE GASKET
|
|
1
|
|
| 8 |
4708213
|
CIRCLIP
|
|
1
|
|
| 9 |
16606034
|
HEXAGON BOLT
|
|
1
|
|
| 10 |
16043324
|
HEXAGON BOLT
|
|
1
|
|
| 11 |
4769427
|
BUSH
|
|
2
|
|
| 12 |
4769710
|
SUPPORT
|
|
1
|
|
| 13 |
16605624
|
HEXAGON BOLT
|
|
5
|
|
|
16605635 |
HEXAGON BOLT |
|
5 |
|
| 14 |
4769596
|
INJ.PUMP DRIV.GEA
|
|
1
|
|
| 15 |
16605734
|
HEXAGON BOLT
|
|
4
|
|
| 16 |
4770452
|
CIRCLIP
|
|
1
|
|
| 17 |
97496177
|
INJECT.PUMP SPIND
|
|
1
|
|
| 18 |
4849361
|
INJECT.PUMP BUSH
|
|
1
|
|
| 19 |
4849996
|
FLAT ENGINE GASKET
|
|
1
|
|
| 20 |
17089474
|
SPRING WASHER
|
|
5
|
|
| 21 |
17085376
|
CIRCLIP
|
|
1
|
|
| 22 |
12164021
|
HEXAGON NUT
|
|
1
|
|
| 23 |
17094914
|
WASHER
|
|
6
|
|
