INJECTORS
Assembly ID: 1420.047
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 756671 | WASHER | 4 | ||
| 2 | 4279495 | RETAINER | 4 | ||
| 3 | 4789864 | NOZZLE HOLDER | 4 | ||
| 4 | 98466050 | FUEL NOZZLE | 4 | ||
| 5 | 11198374 | SPRING WASHER | 4 | ||
| 6 | 11343721 | HEXAGON BOLT | 4 | ||
| 7 | 4279492 | GASKET | 4 | ||
| 8 | 4279493 | BUSH | 4 | ||
| 9 | 4279494 | SEAL GASKET | 4 |
Applies to engines
| Engine | Family | |
|---|---|---|
| 8141.67.2000 | 8141.67 | view |
| 8141i67.02A010 | 8141i67 | view |
