| 1 |
8024318
|
VENTURI HOUSING
|
|
1
|
|
| 2 |
8026802
|
VALVE HOUSING
|
|
1
|
|
| 3 |
8030816
|
HAND M.A.S.
|
|
1
|
|
| 4 |
8030704
|
VENTURI HOUSING
|
|
1
|
|
| 5 |
17279881
|
O-RING
|
|
1
|
|
| 6 |
16689124
|
CYLIND-HEAD SCREW
|
|
4
|
|
| 7 |
16689224
|
SOCKET-HEAD SCREW
|
|
4
|
|
| 8 |
17280181
|
O-RING
|
|
1
|
|
| 9 |
8028142
|
PIPE SOCKET
|
|
1
|
|
| 10 |
17291581
|
O-RING
|
|
2
|
|
| 11 |
16605624
|
HEXAGON BOLT
|
|
6
|
|
|
16605635 |
HEXAGON BOLT |
|
6 |
|
| 12 |
17089874
|
WASHER
|
|
6
|
|
| 13 |
8028298
|
VENTURI
|
|
1
|
|
| 14 |
8028303
|
CONE
|
|
1
|
|
| 15 |
17131270
|
SCREW
|
|
3
|
|
| 16 |
8024440
|
AIR PIPE/DUCT
|
|
1
|
|
| 17 |
8024439
|
PIPE SOCKET
|
|
1
|
|
| 18 |
8024317
|
RETAINER
|
|
1
|
|
| 19 |
8017513
|
RETAINER
|
|
2
|
|
| 20 |
16605424
|
SCREW
|
|
3
|
|
| 21 |
17089474
|
SPRING WASHER
|
|
3
|
|
| 22 |
8023685
|
PIPE SOCKET
|
|
1
|
|
