| 1 |
8108782
|
RUBBER SLEEVE
|
|
6
|
|
| 2 |
8114373
|
CLIP
|
|
8
|
|
|
17765192 |
CLIP |
|
8 |
|
| 3 |
8107953
|
CLIP
|
|
2
|
|
| 4 |
1366290
|
RUBBER LUG
|
|
14
|
|
| 5 |
8010167
|
AIR MANIFOLD
|
|
2
|
|
| 7 |
8114373
|
CLIP
|
|
2
|
|
|
17765192 |
CLIP |
|
2 |
|
| 8 |
8011101
|
RETAINER
|
|
1
|
|
| 9 |
16605424
|
SCREW
|
|
4
|
|
| 10 |
17089474
|
SPRING WASHER
|
|
4
|
|
| 11 |
8107945
|
INTAKE ELBOW
|
|
1
|
|
| 12 |
8107947
|
INTAKE ELBOW
|
|
1
|
|
| 13 |
8009292
|
INTAKE ELBOW
|
|
2
|
|
| 14 |
17291481
|
O-RING
|
|
2
|
|
| 15 |
16605624
|
HEXAGON BOLT
|
|
6
|
|
|
16605635 |
HEXAGON BOLT |
|
6 |
|
| 16 |
17089774
|
SPRING WASHER
|
|
6
|
|
| 17 |
8013481
|
INTAKE ELBOW GASK.
|
|
1
|
|
| 18 |
8013482
|
INTAKE ELBOW GASK.
|
|
1
|
|
| 19 |
15004021
|
HEXAGON BOLT
|
|
6
|
|
| 20 |
17090174
|
SPRING WASHER
|
|
10
|
|
| 21 |
17038121
|
HEXAGON NUT
|
|
2
|
|
|
17038131 |
HEXAGON NUT |
|
2 |
|
| 22 |
17765092
|
CLIP
|
|
4
|
|
| 23 |
8107383
|
RUBBER SLEEVE
|
|
4
|
|
|
99444730 |
RUBBER SLEEVE |
|
4 |
|
| 24 |
8008539
|
AIR MANIFOLD
|
|
2
|
|
| 25 |
4830091
|
CLIP
|
|
4
|
|
|
8019910 |
CLIP |
|
4 |
|
| 26 |
4936328
|
CLIP
|
|
2
|
|
| 27 |
8008599
|
RETAINER
|
|
1
|
|
| 28 |
8008600
|
RETAINER
|
|
1
|
|
| 29 |
16608324
|
HEXAGON BOLT
|
|
2
|
|
|
16608325 |
HEXAGON BOLT |
|
2 |
|
| 30 |
8010168
|
AIR PIPE/DUCT
|
|
1
|
|
| 31 |
8010169
|
AIR PIPE/DUCT
|
|
1
|
|
| 34 |
4858608
|
SEAL GASKET
|
|
2
|
|
| 35 |
16992340
|
THREADED PLUG
|
|
2
|
|
| 36 |
8107954
|
RETAINER
|
|
2
|
|
| 37 |
10923621
|
HEXAGON BOLT
|
|
4
|
|
