| 1 |
4802156
|
AIR PIPE/DUCT
|
|
1
|
|
| 2 |
4817877
|
AIR PIPE/DUCT
|
|
1
|
|
| 3 |
4865230
|
TURBOCHARGER HOSE
|
|
1
|
|
| 4 |
4788410
|
CLIP
|
|
2
|
|
|
17765393 |
CLIP |
|
2 |
|
| 5 |
8005000
|
RETAINER
|
|
1
|
|
| 6 |
17089474
|
SPRING WASHER
|
|
4
|
|
| 7 |
17037931
|
HEXAGON NUT
|
|
2
|
|
| 8 |
8030531
|
TURBOCHARGER HOSE
|
|
1
|
|
| 9 |
8005839
|
CLIP
|
|
2
|
|
|
17769591 |
CLIP |
|
2 |
|
| 10 |
4800661
|
CLIP
|
|
1
|
|
| 11 |
17284681
|
O-RING
|
|
1
|
|
| 12 |
13543121
|
STUD
|
|
2
|
|
| 13 |
16605624
|
HEXAGON BOLT
|
|
2
|
|
|
16605635 |
HEXAGON BOLT |
|
2 |
|
