AIR LINES

Assembly ID: 2423.016

AIR LINES

Parts

# Part number Description Note Quantity
1 4898482 HEXAGON BOLT 4
2 504010786 EXHAUST PIPE 1
3 504030134 FLANGE 1
4 504031827 CLIP 1
5 504035094 FLAT ENGINE GASKET 1

Applies to engines

Engine Family
N45MNSE00.00 NEF 4 mechanic. - TIER 2 view
N45MNSU00.00 NEF 4 mechanic. - TIER 2 view
F4GE0454A*D660 NEF 4 mechanic. - TIER 2 view
F4GE0484C*D650 NEF 4 mechanic. - TIER 2 view
F4GE0454A*D650 NEF 4 mechanic. - TIER 2 view
F4GE0454A*D655 NEF 4 mechanic. - TIER 2 view
N45MNSD00.00 NEF 4 mechanic. - TIER 2 view
N45MNSE00.00A001 NEF 4 mechanic. - TIER 2 view
F4GE0484C*D602 NEF 4 mechanic. - TIER 2 view
N45MNTE20.00A001 NEF 4 mechanic. - TIER 2 view
F4AE0484B*D103 NEF 4 electron. - TIER 2 view
N40ENTD20.00 NEF 4 electron. - TIER 2 view
N40ENTD20.00A800 NEF 4 electron. - TIER 2 view
N40ENTD20.00A801 NEF 4 electron. - TIER 2 view
N45MNSE00.00A002 NEF 4 mechanic. - TIER 2 view
N40ENTE21.00A003 NEF 4 electron. - TIER 2 view
N45MNSD00.00-OM NEF 4 mechanic. - TIER 2 view
N45MNSD00.00A004 NEF 4 mechanic. - TIER 2 view
N40ENTD20.00A810 NEF 4 electron. - TIER 2 view
F4HE9484A*J101 NEF 4 electron. - TIER 3 view
N45ENTX20.00 NEF 4 electron. - TIER 3 view
N45ENTX20.00A001 NEF 4 electron. - TIER 3 view
N45ENTX20.00A003 NEF 4 electron. - TIER 3 view
F4GE9484A*J103 NEF 4 electron. - TIER 3 view
N45ENTX20.00A004 NEF 4 electron. - TIER 3 view
N45ENTX20.00A002 NEF 4 electron. - TIER 3 view
F4AE0484B*D100 NEF 4 electron. - TIER 2 view
N40ENTD20.00A802 NEF 4 electron. - TIER 2 view
F4GE9484J*J602 NEF 4 mechanic. - TIER 3 view
F4GE0457A*D600 NEF 4 mechanic. - TIER 2 view
N45ENTX20.00A007 NEF 4 electron. - TIER 3 view
N45MNTX26.00A001 NEF 4 mechanic. - TIER 3 view
