| 1 |
8028717
|
AIR/WATER HEAT EXCHANGER
|
|
1
|
|
| 2 |
8105947
|
AIR HOOD
|
|
1
|
|
| 3 |
8024498
|
AIR HOOD
|
|
1
|
|
| 4 |
17037821
|
HEXAGON NUT
|
|
4
|
|
| 5 |
8108540
|
AIR MANIFOLD
|
|
1
|
|
| 6 |
16605924
|
SCREW
|
|
10
|
|
| 7 |
16605624
|
HEXAGON BOLT
|
|
28
|
|
|
16605635 |
HEXAGON BOLT |
|
28 |
|
| 8 |
8013481
|
INTAKE ELBOW GASK.
|
|
1
|
|
| 9 |
8008906
|
GASKET
|
|
2
|
|
| 10 |
4858608
|
SEAL GASKET
|
|
2
|
|
| 11 |
16992311
|
LOCK PLUG
|
|
2
|
|
|
16992315 |
LOCK PLUG |
|
2 |
|
| 12 |
18040124
|
SCREW
|
|
4
|
|
| 13 |
8110254
|
SUPPORT
|
|
1
|
|
| 14 |
17089474
|
SPRING WASHER
|
|
32
|
|
| 15 |
17090174
|
SPRING WASHER
|
|
4
|
|
| 16 |
11307021
|
HEXAGON BOLT
|
|
4
|
|
|
11307024 |
HEXAGON BOLT |
|
4 |
|
| 17 |
16730924
|
STUD
|
|
2
|
|
| 18 |
17291281
|
O-RING
|
|
2
|
|
| 19 |
17768191
|
CLIP
|
|
4
|
|
| 20 |
4865234
|
RUBBER SLEEVE
|
|
2
|
|
| 21 |
17037931
|
HEXAGON NUT
|
|
2
|
|
| 22 |
8022777
|
AIR PIPE/DUCT
|
|
1
|
|
| 23 |
8022778
|
BREATHER PIPE
|
|
1
|
|
| 24 |
17290781
|
O-RING
|
|
2
|
|
| 25 |
8108542
|
WATER PIPE
|
|
1
|
|
| 26 |
8013482
|
INTAKE ELBOW GASK.
|
|
1
|
|
| 27 |
16605624
|
HEXAGON BOLT
|
|
6
|
|
|
16605635 |
HEXAGON BOLT |
|
6 |
|
| 28 |
17089774
|
SPRING WASHER
|
|
6
|
|
| 29 |
4742387
|
PLUG
|
|
2
|
|
| 30 |
17089474
|
SPRING WASHER
|
|
8
|
|
| 31 |
8105950
|
FLANGE
|
|
2
|
|
| 32 |
8105951
|
CIRCLIP
|
|
2
|
|
| 33 |
8105952
|
PLATE
|
|
2
|
|
| 34 |
8112975
|
GASKET
|
|
2
|
|
