OIL DIPSTICK
Assembly ID: 2710.123
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 504069978 | COVER | 1 | ||
| 2 | 504055244 | SENSOR | 2 | ||
| 3 | 99489020 | SEAL GASKET | 1 | ||
| 4 | 16673535 | HEXAGON BOLT | 2 | ||
| 5 | 504069933 | SEAL GASKET | 2 | ||
| 6 | 16993315 | THREADED PLUG | 1 |
Applies to engines
| Engine | Family | |
|---|---|---|
| FVQE2883X*A200 | VECTOR 8 | view |
| PPVZ2883X*Q400 | POWER PACK | view |
| PPVZ2883X*Q440 | POWER PACK | view |
