| 1 |
4837950
|
TEMP. TRANSMITTER
|
|
1
|
|
|
504127558 |
TEMP. TRANSMITTER |
|
1 |
|
| 2 |
99443808
|
CONNECTION PIPE
|
|
1
|
|
| 3 |
500345691
|
THERMOSTAT BODY
|
|
1
|
|
| 4 |
10260060
|
SEAL GASKET
|
|
1
|
|
| 5 |
98421297
|
FLAT ENGINE GASKET
|
|
1
|
|
| 6 |
7302944
|
ELBOW COUPLING
|
|
1
|
|
| 7 |
10260160
|
SEAL GASKET
|
|
2
|
|
| 8 |
16866173
|
CIRCLIP
|
|
2
|
|
| 9 |
14455281
|
O-RING
|
|
1
|
|
| 10 |
16605824
|
HEXAGON BOLT
|
|
3
|
|
| 11 |
16605734
|
HEXAGON BOLT
|
|
2
|
|
| 12 |
17089474
|
SPRING WASHER
|
|
6
|
|
| 13 |
4864080
|
SCREW CONNECTOR
|
|
1
|
|
| 14 |
4823212
|
RUBBER GASKET
|
|
1
|
|
| 15 |
16605624
|
HEXAGON BOLT
|
|
1
|
|
|
16605635 |
HEXAGON BOLT |
|
1 |
|
| 16 |
16604924
|
SCREW
|
|
1
|
|
| 17 |
17288481
|
O-RING
|
|
4
|
|
| 18 |
7301254
|
COVER
|
|
1
|
|
| 19 |
98463637
|
THERMOSTAT
|
|
1
|
|
| 20 |
99452677
|
TEMP. TRANSMITTER
|
|
1
|
|
| 21 |
16043724
|
HEXAGON BOLT
|
|
1
|
|
