WATER LINES
Assembly ID: 3253.001
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 4896468 | WATER PIPE | 1 | ||
| 2 | 4896491 | ELBOW COUPLING | 2 | ||
| 3 | 4891285 | THREADED UNION | 1 | ||
| 4 | 4896473 | WATER PIPE | 1 | ||
| 5 | 4897881 | ELBOW COUPLING | 1 | ||
| 6 | 504081274 | THREADED UNION | 1 | ||
| 7 | 98474309 | WASHER | 1 |
Applies to engines
| Engine | Family | |
|---|---|---|
| F4AE0484C*D102 | NEF 4 electron. - TIER 2 | view |
| N40ENTE21.00A002 | NEF 4 electron. - TIER 2 | view |
| F4AE0481A*C103 | NEF 4 electron. - EURO 3 | view |
| F4AE0481A*C106 | NEF 4 electron. - EURO 3 | view |
| F4AE0481C*C102 | NEF 4 electron. - EURO 3 | view |
| F4AE0481A*C118 | NEF 4 electron. - EURO 3 | view |
| F4AE3481D*P103 | NEF 4 electron. - EURO 4 | view |
| F4AE0481C*C111 | NEF 4 electron. - EURO 3 | view |
| N40ENTC21.00L018 | NEF 4 electron. - EURO 3 | view |
| N40ENTC21.00L019 | NEF 4 electron. - EURO 3 | view |
| N40ENTC21.00A014 | NEF 4 electron. - EURO 3 | view |
| N40ENTC21.00A020 | NEF 4 electron. - EURO 3 | view |
| N40ENTC21.00A021 | NEF 4 electron. - EURO 3 | view |
| N40ENTC21.00A022 | NEF 4 electron. - EURO 3 | view |
