WATER LINES
Assembly ID: 3253.004
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 4896468 | WATER PIPE | 1 | ||
| 2 | 4896491 | ELBOW COUPLING | 2 | ||
| 3 | 4891285 | THREADED UNION | 1 | ||
| 4 | 4896476 | WATER PIPE | 1 | ||
| 5 | 4897881 | ELBOW COUPLING | 1 | ||
| 6 | 16500315 | THREADED UNION | 1 | ||
| 7 | 98474309 | WASHER | 1 |
Applies to engines
| Engine | Family | |
|---|---|---|
| F4AE0684N*D103 | NEF 6 electron. - TIER 2 | view |
| N60ENTE24.00A002 | NEF 6 electron. - TIER 2 | view |
| F4AE0682C*C151 | NEF 6 electron. - EURO 3 | view |
| F4AE0681B*C100 | NEF 6 electron. - EURO 3 | view |
| F4AE3682F*P100 | NEF 6 electron. - EURO 4 | view |
| F4AE3682E*P100 | NEF 6 electron. - EURO 4 | view |
| F4AE3681D*P110 | NEF 6 electron. - EURO 4 | view |
| F4AE3682A*R105 | NEF 6 electron. - EURO 4 | view |
| F4AE3682E*R104 | NEF 6 electron. - EURO 4 | view |
| F4AE3682F*R104 | NEF 6 electron. - EURO 4 | view |
| F4AE3681A*R100 | NEF 6 electron. - EURO 4 | view |
| F4AE3681D*R107 | NEF 6 electron. - EURO 4 | view |
| F4AE3681B*R107 | NEF 6 electron. - EURO 4 | view |
| F4AE0681A*C157 | NEF 6 electron. - EURO 3 | view |
