TEMPERATURE REGULATOR
Assembly ID: 3260.001
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 504062828 | OIL/WATER HEAT EXCHANGER | 1 | ||
| 2 | 14471181 | O-RING | 2 | ||
| 3 | 16587425 | HEXAGON BOLT | 6 | ||
| 4 | 8094798 | HEAT EXCHANG.COVER | 1 | ||
| 5 | 8094799 | HEAT EXCHANG.COVER | 1 | ||
| 6 | 8094800 | TUBE STACK | 1 | ||
| 7 | 8029428 | SPACING BAR | 1 | ||
| 8 | 16690924 | CYLIND-HEAD SCREW | 8 | ||
| 9 | 8030481 | O-RING | 4 |
Applies to engines
| Engine | Family | |
|---|---|---|
| FVQE2883X*A200 | VECTOR 8 | view |
| PPVZ2883X*Q400 | POWER PACK | view |
| FVQE2883X*A201 | VECTOR 8 | view |
| PPVZ2883X*Q440 | POWER PACK | view |
| FVQE2883X*A202 | VECTOR 8 | view |
| FVAE2885X*A100 | VECTOR 8 | view |
| VECTOR8TE2.A001 | VECTOR 8 | view |
| V08ENTM11.10D210 | VECTOR 8 | view |
| V08ENTM75.10A210 | VECTOR 8 | view |
| V08ENTM75.10B210 | VECTOR 8 | view |
| V08ENTM75.10B230 | VECTOR 8 | view |
| V08ENTM11.10C210 | VECTOR 8 | view |
| V08ENTM11.10P210 | VECTOR 8 | view |
| V08ENTM11.10R210 | VECTOR 8 | view |
| V08ENTM12.10A210 | VECTOR 8 | view |
| V08ENTM12.10B210 | VECTOR 8 | view |
| FVAE2884A*B200 | VECTOR 8 | view |
| FVAE2884A*B201 | VECTOR 8 | view |
| FVAE2884X*B200 | VECTOR 8 | view |
| VECTOR8TE2.A002 | VECTOR 8 | view |
| GEVECTOR650E.A500 | GEVECTOR 8 - TIER 2 | view |
| FVQE2883Z*C200 | VECTOR 8 | view |
