| 1 |
8018494
|
WATER RADIATOR
|
|
1
|
|
| 2 |
8007076
|
WATER RADIATOR
|
|
1
|
|
| 3 |
741571
|
SPACING BAR
|
|
2
|
|
|
FPT741571 |
SPACING BAR |
|
2 |
|
| 4 |
8014848
|
PROTECTION
|
|
1
|
|
| 5 |
741570
|
WASHER
|
|
8
|
|
| 6 |
741569
|
RUBBER LUG
|
|
8
|
|
| 7 |
8107632
|
RADIATOR PLUG
|
|
1
|
|
| 8 |
8105096
|
PLUG
|
|
1
|
|
| 9 |
8018492
|
AIR/AIR INTERCOOLER
|
|
1
|
|
| 10 |
8108634
|
SPACING BAR
|
|
2
|
|
| 11 |
16605424
|
SCREW
|
|
4
|
|
| 12 |
8014327
|
PROTECTION
|
|
1
|
|
| 13 |
17090174
|
SPRING WASHER
|
|
2
|
|
| 14 |
17038421
|
HEXAGON NUT
|
|
2
|
|
|
17038425 |
HEXAGON NUT |
|
2 |
|
| 15 |
8114381
|
TIE ROD
|
|
1
|
|
| 16 |
8114382
|
TIE ROD
|
|
1
|
|
| 17 |
8008159
|
GASKET
|
|
1
|
|
| 18 |
10300511
|
LOCK PLUG
|
|
1
|
|
| 19 |
10298460
|
SEAL GASKET
|
|
1
|
|
| 20 |
10300611
|
LOCK PLUG
|
|
2
|
|
|
16992315 |
LOCK PLUG |
|
2 |
|
| 21 |
4858608
|
SEAL GASKET
|
|
3
|
|
| 22 |
17037931
|
HEXAGON NUT
|
|
21
|
|
| 23 |
17091074
|
WASHER
|
|
6
|
|
| 24 |
17089474
|
SPRING WASHER
|
|
20
|
|
| 25 |
17038221
|
HEXAGON NUT
|
|
2
|
|
|
17038225 |
HEXAGON NUT |
|
2 |
|
| 26 |
16610724
|
SCREW
|
|
2
|
|
| 27 |
15004021
|
HEXAGON BOLT
|
|
2
|
|
| 28 |
17038621
|
NUT
|
|
4
|
|
| 29 |
17094914
|
WASHER
|
|
12
|
|
| 30 |
17089774
|
SPRING WASHER
|
|
6
|
|
| 31 |
16605624
|
HEXAGON BOLT
|
|
10
|
|
|
16605635 |
HEXAGON BOLT |
|
10 |
|
| 32 |
16605424
|
SCREW
|
|
6
|
|
| 33 |
8107633
|
PROTECTION
|
|
1
|
|
| 34 |
16603624
|
HEXAGON BOLT
|
|
16
|
|
| 35 |
17088974
|
SPRING WASHER
|
|
16
|
|
