| 1 |
4918846
|
O-RING
|
|
1
|
|
| 2 |
14056240
|
NUT
|
|
1
|
|
| 3 |
4918908
|
TIE ROD
|
|
1
|
|
| 4 |
4918921
|
GASKET
|
|
1
|
|
| 5 |
8077052
|
WATER/SEA WATER HEAT EXCH
|
|
1
|
|
| 6 |
8110556
|
SUPPORT
|
|
1
|
|
| 7 |
4930157
|
GASKET
|
|
1
|
|
| 8 |
8110555
|
RETAINER
|
|
1
|
|
| 9 |
4929632
|
TUBE STACK
|
|
1
|
|
| 10 |
15971821
|
SCREW
|
|
2
|
|
| 11 |
8015958
|
HEAT EXCHANG.COVER
|
|
1
|
|
| 12 |
4934733
|
HEAT EXCHANG.COVER
|
|
1
|
|
| 14 |
10260160
|
SEAL GASKET
|
|
2
|
|
| 15 |
10298460
|
SEAL GASKET
|
|
1
|
|
| 16 |
17090474
|
SPRING WASHER
|
|
4
|
|
| 17 |
15004021
|
HEXAGON BOLT
|
|
2
|
|
| 18 |
17090174
|
SPRING WASHER
|
|
5
|
|
| 19 |
15970521
|
HEXAGON BOLT
|
|
1
|
|
|
15970524 |
HEXAGON BOLT |
|
1 |
|
| 20 |
11343721
|
HEXAGON BOLT
|
|
1
|
|
| 21 |
11306921
|
SCREW
|
|
1
|
|
| 22 |
4723225
|
CHOCK
|
|
1
|
|
| 23 |
15973121
|
HEXAGON BOLT
|
|
2
|
|
| 24 |
4930462
|
PLUG
|
|
1
|
|
|
8052206 |
PLUG |
|
1 |
|
| 25 |
11903140
|
PLUG
|
|
2
|
|
| 26 |
10305140
|
LOCK PLUG
|
|
1
|
|
| 28 |
14163670
|
DOWEL PIN
|
|
1
|
|
| 29 |
14163870
|
PIN
|
|
1
|
|
| 30 |
10279560
|
SEAL GASKET
|
|
1
|
|
| 31 |
10265360
|
SEAL GASKET
|
|
1
|
|
| 32 |
8102030
|
FILLER NECK
|
|
1
|
|
| 33 |
14282770
|
LOCK PLUG
|
|
3
|
|
|
16991170 |
LOCK PLUG |
|
3 |
|
| 34 |
4918844
|
WASHER
|
|
1
|
|
| 35 |
14161370
|
PIN
|
|
1
|
|
|
17252170 |
PIN |
|
1 |
|
| 37 |
13516821
|
STUD
|
|
1
|
|
|
16729324 |
STUD |
|
1 |
|
| 38 |
13517721
|
STUD
|
|
1
|
|
