FRESH WATER - SEA WATER HEAT EXCHANGER
Assembly ID: 3370.052
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 8040642 | SUPPORT | 1 | ||
| 2 | 16677735 | HEXAGON BOLT | 2 | ||
| 3 | 8036074 | WATER/SEA WATER HEAT EXCH | 1 | ||
| 4 | 17094914 | WASHER | 3 | ||
| 5 | 16045424 | SCREW | 3 | ||
| 6 | 17289681 | O-RING | 4 | ||
| 7 | 8018308 | CONNECTOR SLEEVE | 2 | ||
| 8 | 16600224 | HEXAGON BOLT | 1 |
Applies to engines
| Engine | Family | |
|---|---|---|
| N60ENTF40.00 | NEF 6 electron. | view |
| N67MNTF40.01A001 | NEF 6 mechanic. - TIER 2 | view |
| N67MNTF41.00A001 | NEF 6 mechanic. | view |
| N67MNTF42.00A001 | NEF 6 mechanic. | view |
