HAND ACCELERATOR
Assembly ID: 5600.000
Parts
| # | Part number | Description | Note | Quantity | |
|---|---|---|---|---|---|
| 1 | 8114237 | RETAINER | 1 | ||
| 2 | 8113693 | RETAINER | 1 | ||
| 3 | 16603624 | HEXAGON BOLT | 2 | ||
| 4 | 17088474 | WASHER | 2 | ||
| 5 | 17037821 | HEXAGON NUT | 2 | ||
| 6 | 14358821 | SCREW | 2 | ||
| 7 | 11199279 | SPRING WASHER | 2 |
Applies to engines
| Engine | Family | |
|---|---|---|
| 8031M06.01 | 8031M06 | view |
| 8031M06.21 | 8031M06 | view |
| 8041M08.01 | 8041M08 | view |
| 8041M08.21 | 8041M08 | view |
