| 1 |
8036038
|
WATER RADIATOR
|
|
1
|
|
| 2 |
17765091
|
CLIP
|
|
8
|
|
| 3 |
98421391
|
RUBBER SLEEVE
|
|
3
|
|
| 4 |
8042060
|
WATER PIPE
|
|
1
|
|
| 5 |
8041922
|
RUBBER SLEEVE
|
|
1
|
|
| 6 |
8042565
|
WATER PIPE
|
|
1
|
|
| 7 |
8019397
|
RETAINER
|
|
1
|
|
| 8 |
16605524
|
HEXAGON BOLT
|
|
2
|
|
| 9 |
17089474
|
SPRING WASHER
|
|
2
|
|
| 10 |
17091074
|
WASHER
|
|
4
|
|
| 11 |
17038425
|
HEXAGON NUT
|
|
4
|
|
| 12 |
8043420
|
TIE ROD
|
|
1
|
|
| 13 |
8041985
|
RETAINER
|
|
1
|
|
| 14 |
4788410
|
CLIP
|
|
6
|
|
|
17765393 |
CLIP |
|
6 |
|
| 15 |
8043728
|
RUBBER SLEEVE
|
|
1
|
|
| 16 |
8044489
|
AIR PIPE/DUCT
|
|
1
|
|
| 17 |
8043612
|
RUBBER SLEEVE
|
|
1
|
|
| 18 |
8044863
|
RUBBER SLEEVE
|
|
1
|
|
| 19 |
8044864
|
AIR PIPE/DUCT
|
|
1
|
|
| 20 |
8030531
|
TURBOCHARGER HOSE
|
|
1
|
|
| 21 |
8041915
|
CONNECTOR SLEEVE
|
|
1
|
|
| 22 |
17291281
|
O-RING
|
|
1
|
|
| 23 |
99435103
|
CLIP
|
|
1
|
|
| 24 |
4935727
|
PIPE SOCKET
|
|
1
|
|
| 25 |
4935134
|
OIL LINE
|
|
1
|
|
| 26 |
4858607
|
WASHER
|
|
1
|
|
| 27 |
18087993
|
CLIP
|
|
2
|
|
| 28 |
8034635
|
BREATHER PIPE
|
|
1
|
|
| 29 |
10284460
|
SEAL GASKET
|
|
1
|
|
| 30 |
61318365
|
AIR PIPE/DUCT
|
|
1
|
|
| 31 |
17284681
|
O-RING
|
|
1
|
|
| 32 |
4800661
|
CLIP
|
|
1
|
|
| 33 |
741569
|
RUBBER LUG
|
|
2
|
|
| 34 |
741570
|
WASHER
|
|
2
|
|
| 35 |
17090174
|
SPRING WASHER
|
|
2
|
|
| 36 |
16607524
|
HEXAGON BOLT
|
|
2
|
|
| 37 |
741571
|
SPACING BAR
|
|
1
|
|
|
FPT741571 |
SPACING BAR |
|
1 |
|
| 38 |
8049678
|
RUBBER SLEEVE
|
|
1
|
|
| 39 |
98421391
|
RUBBER SLEEVE
|
|
2
|
|
| 40 |
17765091
|
CLIP
|
|
6
|
|
